The Chest — Technical specifications
Overview
| Designer | Studio Pavia |
|---|
| Production | Belgium and EU |
|---|
| Assembly | Hand-assembled in the atelier |
|---|
| Availability | Produced in small batches |
|---|
Dimensions & weight
Size S
| Outer dimensions (W×D×H) | 480×650×550mm |
|---|
| Inner dimensions (W×D×H) | 450×490×510mm |
|---|
| Door opening (W×H) | 342×500mm |
|---|
| Weight | 15 kg |
|---|
Size M
| Outer dimensions (W×D×H) | 550×830×620mm |
|---|
| Inner dimensions (W×D×H) | 520×570×580mm |
|---|
| Door opening (W×H) | 414×580mm |
|---|
| Weight | 18 kg |
|---|
Dimensions may vary slightly due to material tolerances and finishing.
Materials & finishes
Wood
| Material | Beech plywood |
| Thickness | 15mm |
| Certification | FSC® certified |
| Finish | Clear varnish |
| Appearance | Natural, matte |
Acrylic door
| Material | PMMA XT |
| Thickness | 6 mm |
| Transparency | Clear |
| Mounting | Hettich rail and hinge system |
Construction
| Demountable | Lamello Clamex system, hex screws |
| Hole diameter | Ø12mm |
| Slot size | Ø30×60L |
| Rear openings | 2 vertical openings of H×50mm |
Textile
| Type | Removable cushion with zipper |
| Cover | Outdoor-grade upholstery fabric, water-repellent and abrasion-resistant |
| Filler | High-resilience foam |
| Colours | Green, white and red |
Use & maintenance
Use
| Intended for dogs that can rest calmly in an enclosed space. |
| Not suitable for dogs that panic, chew destructively, or attempt to escape. |
| Use should be introduced gradually and remain voluntary for the dog. |
| Not intended for transport or unsupervised confinement. |
Maintenance
| Clean with a dry or slightly damp cloth. |
| Do not use abrasive or aggressive cleaning agents. |
| Avoid prolonged exposure to moisture. |
| Cushion cover washable at 60°C. |
For further information, please
contact us.
